IP Line Surveillance Terminal

Product introduction

Datasheet download

Video

Features:

16-zone selector via IP manual/auto control
16 lines supervising via IP
Line auto checking duration setting 3min~6hours,with knob control
Line manual checking by buttons
Build in monitoring speaker
Checking time: 30ms
Advanced checking technology with impendance + current checking
1 x 16 mode, 2 x 8 mode and 16x16 mode for choice
Normal / Short Circuit /Open Circuit with LED indicators
Auto alarm with local buzzer or via network
Support BGM amplifier+Paging amplifier mode
Support max 16 amplifier inputs under 16x16 mode, can divide any amplifier into any
zones conveniently.
800W max for each channel
High performance ARM processor, can realize the excellent network audio
transmission performance.
B/S structure and can be managed via web browser.
Advanced network structure design, support standalone running without server.
High reliability and stability with industrial level.
Communication delay < 50 ms.
Built in 4 Timing program schedules to control the system automatically.

Can upload music or upgrade software via USB or TF card.
